LED Marker | Nova Series | 180º Amber Strobe

Features

• High Lumen Output – Bright, clear visibility

• 180º Light Output - Wide visibility
• Premium Build – Durable, high-quality materials

• IP67 Rated – Dust-tight & water resistant.

• Sealed + Vented – No moisture or condensation

• Vibration & Shock Resistant – Built for tough use

• Long Lifespan – Reliable, low maintenance

• Energy Efficient – Low power, high performance

Specification

IP Rating: IP67
Cable length: 200mm
Voltage: 12/24v | DC 10-30v
Housing Material: High-grade Aluminium
Lens Material: PC | Scratch resistant
Operating temperature: -20℃ - +60℃
Certification: ECE R65/R10/SAE J595
Width: 90mm | Height: 13mm | Depth: 33mm
Strobe Wattage: 3w

Fitment

These units are great for any 12v or 24v application such as a car, van, trailer, 4x4, Bus or lorry.

Connections
Red: Strobe +
Black: Negative -
White: Alternation With the power off, connect the wire from one light head to +VDC and leave the other unconnected.Their patterns will alternate when the light heads are activated.
Yellow: Synchronisation / Flash Pattern Selection / Reset
Connect Yellow wires of all heads together for synchronisation
To change flash patterns, apply+VDC for less than 1 second and release
Flash patterns will be reset when Yellow wires are connected to Red
wire for more than 5
Green: Dim Mode

Flash patterns

1. Random (Default)
2. R65 Single (All)
3. Double (All)
4. Single (All)
5. Double (All)
6. Quad (All)
7. Quint (All)
8. Nonuplet (All)
9. Single - Quad (All)
10. Single - Nonuplet (All)
11. Single (Split)
12. Double (Split)
13. Quad (Split)
14. Quint (Split)
15. Nonuplet (Split)
16. Single - Quad (Split)
17. Single - Nonuplet (Split)
18. Steady 2 (California)
19. Steady 2
20. Steady (All)

What's in the box

1x LED Marker light
1x Bracket
1x Fixing Kit

Other Information

Models may vary. Ensure fitment is correct for the vehicle before purchase. Packaging type may vary depending on stock and shipping restrictions.

Warranty: 2 Years
